Baru Total Station Gowin TKS202N

Total Station Gowin TKS202N

Call for price

Tambahkan ke Wishlist

whatsapp

Baru

Gowin mengeluarkan produk baru seri Total Station Gowin TKS202N, dilengkapi dengan kemampuan laser sampai 400 meter membuat type ini layak diperhitungkan. Total station Gowin TKS202n mempunyai ketelitian sudut dua detik, dengan tampilan dua muka sehingga memudahkan surveyor untuk melakukan pengukuran.

Fiture unggulan dari Total station Gowin TKS 202 n

  •  2″ angle accuracy provides 1/16th of an inch accuracy at 1,000ft.
  •   Dual keyboards with and expanded numeric keypad for faster data input.
  •   Accurately measure up to 2,000m with a single prism.
  •   Reflectorless : 400M
  •   Internal data storage for up to 24,000 points.
  •   Single axis compensator with ±3′ compensating range.
  •   IP54 environmental protection rating

Spesifikasi Teknis:

Gowin Total Station TKS-202 Technical Specifications:
Model Name     Gowin TKS-202
Telescope     Objective Lens Diameter     45mm (EDM: 50mm)
Magnification     30x
Image     Erect
Field of View     1°30′
Resolving Power     3.0″
Min. Focus Distance     1.3m
Angle Measurement     Accuracy     2″
Method     Absolute
Minimum Reading     1″/5″
Distance Measurement
Distance Range     1 Prism     2,000
3 Prisms     2,700m
Accuracy     ±(+2mm + 2ppm x D**)m.s.e.
Measuring Time     Fine Measurement Mode     1.2 sec.(Intial 4 sec.)
Coarse Measurement Mode     0.7 sec.
Tracking Measurement Mode     0.4 sec.
Atmospheric Correction Range     Yes
Prism Constant Correction Range     Yes
Software & Memory
On-Board Software Functions     Data Collection, Resection, Road, Stakeout, Area Calculation, Height Measurement, etc.
Internal Memory     24,000 points
Interface     RS-232C (Standard)
Display     Display Unit     Graphics LCD, 2 Sides
Keyboard     24-Alpha-Numeric Key
Tilt Correction (Automatic Index)
Tilt Sensor     Yes
Correction Method     Liquid Type
Compensating Range     ± 3′
Level Senstivity
Plate Level     30″/2mm
Circular Level     10’/2mm
Optical Plummet Telescope
Image     Erect
Magnification     3x
Focusing Range     0.5 to infinity
Field of View     3° and above
Others
Protection against water and dust***     IP 54 (with BT-L1 Battery)
Operating Temperature     -20°C~+50°C (-4°F~+122°F)
Dimension     336 (H) x 184 (W) x 172 (L)mm
Weight (with Battery)     4.8Kg
On Board Battery     BT-L1 (Lithium-ion)
Battery Charger     BC-L1
Maximum Operating Time
Including Distance Measurement     14 Hours
Angle Measurement Only     60 Hours
Output Voltage     DC 10

Paket pembelian :

- Unit Total Station Gowin TKS202N
- 2 X Tripod
- 1 X Single prisma
- 1X Prisma polygon
- Software Transfer
- Hardcase
- Manual book
- Sertifikat kalibrasi
- Garansi resmi 1 tahun
- Pelatihan penggunaan alat dan aplikasinya untuk survey
